ICS-230 Ice Cream Cone Sleeve Making Machine

ICS-230 Ice Cream Cone Sleeve Making Machine

ICS-230 automatic paper cone sleeve machine makes paper cone sleeve for ice cream. This high speed machine can shape angles from 17°-28° (By changing the mould).


Product Code - ICS-230

Brand - Prasanna Machines

Compare

ICS-230 automatic paper cone sleeve machine makes paper cone sleeve for ice cream. This high speed machine can shape angles from 17°-28° (By changing the mould). Major parts of this machine are installed with well-known International brands like Schneider. Panasonic, Robatech etc.

The sucking mouth will suck the paper, which has been printed previously, from the paper bracket to the transportation chain, and then transport it to the forming mould. During the Transportation, the paper will be spread with hot-melt glue. After the formation, the paper spread with glue will be automatically blown to be transported to the auto collecting unit. The piling and counting are automatic, and the paper will be carried out according to the pre arranged piling numbers without stopping the machine.

Cone Size4-10 Oz
Speed190-230 Pieces/Minute
Suitable Paper Weight80-170 gsm
Paper SpecificationArt Paper, Aluminized Paper, Wax Paper
Angle Degree17-28°
Power220V/380V 50Hz, 9 KW
Weight1000 Kg
Overall Dimension (L*W*H)1850L*1750W*1800H mm
